Description
Style 115 flared trough end for 16″ screw conveyor with 3″ self-aligning ball bearing is designed with a top flange to support the cover and a bottom flange which serves as feet for the screw conveyor. Our flared trough ends are manufactured from high-quality heavy-gauge steel for superior strength and holding capacity over time. 115 flared trough ends are designed to specifically fit a flared trough. Typically, 115 trough ends are fitted with a self-aligning ball bearing but additional bearing types are available such as bronze, Arguto wood, nylon, bronze oilite, and it can be fitted with a Chevron or Hammond end thrust bearing as well. For more information or to get a quote on #115 flared trough end for 16″ screw conveyor with 3″ ball bearing contact us and our customer service team will be happy to assist you!
115 Flared Trough End For 16″ Conveyor With 3″ Bearing Dimensions
- Part #: 230-1752-115
- Diameter of Conveyor: 16″
- Bearing Bore: 3″
- Dimension (A): 32-1/2″
- Dimension (B): 3-7/8″
- Dimension (C): 2-1/2″
- Dimension (D): 11-1/2″
- Dimension (E): 12″
- Dimension (F): 2″
- Dimension (G): 3-1/4″
- Dimension (H): 5/8″
- Dimension (J): 14-7/8″
- Dimension (K): 3/8″
- Weight With Bearing: 146 LBS
